Fuse 1000VDC aBat 60A 22x65mm
972.091.49
| Series name | AB22 | Power loss (W) | 11 |
| Rated current In (A) | 60 | Class | aBat |
| Rated Voltage Un DC (V) | 1000 | Rated breaking capacity I1 DC (kA) | 10 |
| Time costant L/R (ms) | 1-3 | Fuse Connection/Terminal type | Cylindrical |
| Melting I²t value (A²s) | 1270 | Total clearing I²t @Un DC (A²s) | 7000 |
| Minimum breaking current (A) | 480 | Applicable standards | IEC |
