Fuse 1000VDC aBat 800A 89x106mm 2x M12 flush end terminals
577.531.20
| Series name | B301 | Power loss (W) | 170 |
| Rated current In (A) | 800 | Class | aBat |
| Fuse Dimension (mm) | 86x106 | Rated Voltage Un DC (V) | 1000 |
| Rated breaking capacity I1 DC (kA) | 50 | Time costant L/R (ms) | 2 |
| Fuse Connection/Terminal type | Screw fixing | Melting I²t value (A²s) | 149700 |
| Fixing dimensions | M12 | Total clearing I²t @Un DC (A²s) | 520000 |
| Minimum breaking current (A) | 6400 | Applicable standards | IEC |
