Fuse 1000VDC aBat/aR 630A 63x167mm tin plated axial terminals, fixing centres 132mm
428.074.55
| Series name | B100 | Power loss (W) | 120 |
| Rated current In (A) | 630 | Class | aBat |
| Fuse Dimension (mm) | 63x167 | Rated Voltage Un DC (V) | 1000 |
| Rated breaking capacity I1 DC (kA) | 100 | Fixing connection centres (mm) | 132,75 |
| Time costant L/R (ms) | 2 | Fuse Connection/Terminal type | Screw fixing |
| Melting I²t value (A²s) | 108000 | Total clearing I²t @Un DC (A²s) | 324000 |
| Minimum breaking current (A) | 6300 | Applicable standards | IEC, UL |
