Fuse 1000VDC aR 32A 22x65mm
868.215.71
| Series name | AR22 | Power loss (W) | 5,3 |
| Rated current In (A) | 32 | Class | aR |
| Fuse Dimension (mm) | 22x65 | Rated Voltage Un DC (V) | 1000 |
| Rated breaking capacity I1 DC (kA) | 50 | Time costant L/R (ms) | 1-3 |
| Fuse Connection/Terminal type | Cylindrical | Melting I²t value (A²s) | 250 |
| Total clearing I²t @Un DC (A²s) | 2000 | Applicable standards | IEC |
