Fuse 500VAC IEC/550VAC UL aR 125A 22x58mm with pins for PCB soldering
743.702.10
| Series name | UR22 | Power loss (W) | 26 |
| Rated current In (A) | 125 | Class | aR |
| Rated Voltage Un AC (V) | 690 | Rated breaking capacity I1 AC (kA) | 200 |
| Fuse Dimension (mm) | 22x58 | Fixing connection centres (mm) | 80 |
| Fuse Connection/Terminal type | Cylindrical | Melting I²t value (A²s) | 3100 |
| Total clearing I²t @Un AC (A²s) | 15000 | Applicable standards | IEC |
