Fuse 690VAC/700VDC aR 100A DIN000/80 with indicator and with lug for microswitch fitting - fixing centres 80mm
563.521.70
| Series name | NR2A | Power loss (W) | 19 |
| Rated current In (A) | 100 | Class | aR |
| Indicator | Yes | Rated Voltage Un AC (V) | 690 |
| Rated breaking capacity I1 AC (kA) | 200 | Rated Voltage Un DC (V) | 700 |
| Fuse size | NH000 | Rated breaking capacity I1 DC (kA) | 30 |
| Fixing connection centres (mm) | 80 | Time costant L/R (ms) | 2 |
| Fuse Connection/Terminal type | Screw fixing | Melting I²t value (A²s) | 1340 |
| Total clearing I²t @Un AC (A²s) | 5000 | Total clearing I²t @Un DC (A²s) | 5850 |
| Applicable standards | IEC |
