Fuse 690VAC aR 12A 14x51mm
658.591.15
| Series name | A145 | Power loss (W) | 3,6 |
| Rated current In (A) | 12 | Class | aR |
| Rated Voltage Un AC (V) | 690 | Rated breaking capacity I1 AC (kA) | 200 |
| Fuse Dimension (mm) | 14x51 | Fuse Connection/Terminal type | Cylindrical |
| Melting I²t value (A²s) | 9 | Total clearing I²t @Un AC (A²s) | 78 |
| Applicable standards | IEC |
