Fuses

Fuse 500VAC IEC/550VAC UL aR 40A 22x58mm surface mount,...

Reference: 100.913.34

Series name: UR22

Power loss (W): 9,6

Rated current In (A): 40

Class: aR

Rated Voltage Un AC (V): 690

Rated breaking capacity I1 AC (kA): 200

Fuse Dimension (mm): 22x58

Fixing connection centres (mm): 80

Fuse Connection/Terminal type: Cylindrical

Melting I²t value (A²s): 148

Total clearing I²t @Un AC (A²s): 640

Applicable standards: IEC

Available

3D Datasheet

Compare

Fuse 690VAC aR 6300A size 2 61x50mm M10 flush end terminals

Reference: 111.779.56

Series name: C200

Power loss (W): 80

Rated current In (A): 630

Class: aR

Rated Voltage Un AC (V): 690

Rated breaking capacity I1 AC (kA): 200

Fuse Dimension (mm): 61x50

Fuse Connection/Terminal type: Screw fixing

Melting I²t value (A²s): 55500

Total clearing I²t @Un AC (A²s): 305000

Applicable standards: IEC

Available

3D Datasheet

Compare

Fuse 500VAC IEC/550VAC UL aR 135A 22x58mm with pins for...

Reference: 114.304.22

Series name: UR22

Power loss (W): 28,6

Rated current In (A): 135

Class: aR

Rated Voltage Un AC (V): 500

Rated breaking capacity I1 AC (kA): 200

Fuse Dimension (mm): 22x58

Fixing connection centres (mm): 80

Fuse Connection/Terminal type: Cylindrical

Melting I²t value (A²s): 3640

Total clearing I²t @Un AC (A²s): 17800

Applicable standards: IEC

Available

3D Datasheet

Compare

Fuse 690VAC aR 550A size 1 53x52mm M8 flush end terminals

Reference: 114.997.24

Series name: C100

Class: aR

Rated Voltage Un AC (V): 690

Rated breaking capacity I1 AC (kA): 100

Fuse Dimension (mm): 53x52

Applicable standards: IEC

Available

3D Datasheet

Compare

Fuse 690VAC aR 160A size 1 53x52mm M8 flush end terminals

Reference: 115.115.26

Series name: C100

Class: aR

Rated Voltage Un AC (V): 690

Rated breaking capacity I1 AC (kA): 100

Fuse Dimension (mm): 53x52

Applicable standards: IEC

Available

3D Datasheet

Compare

Fuse 500VAC IEC/550VAC UL aR 50A 22x58mm surface mount,...

Reference: 123.063.29

Series name: UR22

Power loss (W): 13,3

Rated current In (A): 50

Class: aR

Rated Voltage Un AC (V): 690

Rated breaking capacity I1 AC (kA): 200

Fuse Dimension (mm): 22x58

Fixing connection centres (mm): 80

Fuse Connection/Terminal type: Cylindrical

Melting I²t value (A²s): 195

Total clearing I²t @Un AC (A²s): 955

Applicable standards: IEC

Available

3D Datasheet

Compare

Fuse 500VAC gG/550VAC gR 100A 27x60mm with pins for PCB...

Reference: 171.902.24

Series name: G276

Rated current In (A): 100

Class: gG

Rated Voltage Un AC (V): 500

Rated breaking capacity I1 AC (kA): 100

Fuse Connection/Terminal type: PCB Mount Terminals

Applicable standards: IEC

Available

Datasheet

Compare

Fuse 500VAC gG/550VAC gR 100A 27x60mm

Reference: 321.659.62

Series name: G276

Rated current In (A): 100

Class: gG

Rated Voltage Un AC (V): 500

Rated breaking capacity I1 AC (kA): 100

Fuse Dimension (mm): 27x60

Fuse Connection/Terminal type: Cylindrical

Applicable standards: IEC

Available

Datasheet

Compare

Fuse 500VAC gG/550VAC gR 125A 27x60mm

Reference: 344.575.93

Series name: G276

Rated current In (A): 125

Class: gG

Rated Voltage Un AC (V): 500

Rated breaking capacity I1 AC (kA): 100

Fuse Dimension (mm): 27x60

Fuse Connection/Terminal type: Cylindrical

Applicable standards: IEC

Available

Datasheet

Compare

Fuse 500VAC gG/550VAC gR 160A 27x60mm with pins for PCB...

Reference: 858.953.83

Series name: G276

Rated current In (A): 160

Class: gG

Rated Voltage Un AC (V): 500

Rated breaking capacity I1 AC (kA): 100

Fuse Dimension (mm): 27x60

Fuse Connection/Terminal type: PCB Mount Terminals

Applicable standards: IEC

Available

Datasheet

Compare

Fuse 500VAC gG/550VAC gR 160A 27x60mm

Reference: 934.168.97

Series name: G276

Rated current In (A): 160

Class: gG

Rated Voltage Un AC (V): 500

Rated breaking capacity I1 AC (kA): 100

Fuse Dimension (mm): 27x60

Fuse Connection/Terminal type: Cylindrical

Applicable standards: IEC

Available

Datasheet

Compare

Fuse 500VAC gG/550VAC gR 125A 27x60mm with pins for PCB...

Reference: 954.427.00

Series name: G276

Rated current In (A): 125

Class: gG

Rated Voltage Un AC (V): 500

Rated breaking capacity I1 AC (kA): 100

Fuse Dimension (mm): 27x60

Fuse Connection/Terminal type: PCB Mount Terminals

Applicable standards: IEC

Available

Datasheet

Compare
